Specification Parameters
Order number: STD5350P05
Name: ABB IRB5350 Spray Robot Protective Clothing
Jellemzők:Anti-dust, anti-static, anti paint
Robot operating conditions: powder spraying, spray painting, spray painting
Scope of application: ABB industrial robots
Size specification: ABB IRB5350
| No. | Parameter Name | Value/Grade | Unit/Description | Performance Association Analysis |
|---|---|---|---|---|
| 1 | Charge Surface Density | 0.9 | μC/m² (Microcoulomb per square meter) | Electrostatic Generation Capacity: Higher values indicate stronger electrostatic charge generation capacity after friction. 0.9 μC/m² is considered moderate. |
| 2 | Electrostatic Half-life | 0.2 | Seconds (s) | Electrostatic Dissipation Speed: Smaller values indicate faster electrostatic dissipation. 0.2 seconds indicates excellent antistatic performance. |
| 3 | Electrostatic Voltage | 91 | Volts (V) | Electrostatic Accumulation Level: Lower voltages result in less electrostatic shock sensation upon human contact. 91 V falls within the low electrostatic accumulation range. |
| 4 | Point-to-point Resistance | 2.1×10⁷ | Ohms (Ω) | Electrical Conductivity Characterization: This resistance value meets antistatic fabric standards (typically 10⁶-10⁹ Ω) and can effectively dissipate electrostatic charges. |
| 5 | Flame Retardancy Grade | Grade 1 | National Standard Grading | Fire Safety: Grade 1 is the highest flame retardancy grade, indicating excellent flame retardant properties and resistance to combustion upon contact with fire. |
Spraying robots, instead of manpower can improve the quality of spray and material usage, but the various types of spray coating materials in the long-term operation of the robot will also damage the robot arm. In particular, for the paint pump, the robot body is inevitably in the paint spray explosive environment during the work. The installation of spray robot protective clothing is very important, it can isolate the robot from static, dust, flammable, etc.
1. Anti-static, flame retardant: to avoid the production of a large number of static electricity, eliminating the accumulation of static that may cause burning, explosion, and other security incidents.
2. Dust-proof, oil-resistant: Avoid paint dust collection dripping on the body to improve the efficiency of the spray robot
3. Good flexibility: spray the robot's flexible parts and telescopic parts, specially designed by the professional, to avoid spraying the robot when the multi-angle rotation tears spray robot's protective clothing
4. Removable, easy to install the design, you can always remove the down maintenance, especially for regular debugging, and maintenance of the robot, a significant savings in labor costs
Advantages of spray robot protective clothing
Spraying robot protective clothing adopts high-performance textile materials with good scalability. It has function of anti-static, dustproof, flame retardant, anti-pilling, fluff, and other characteristics, suitable for all kinds of spray robots used in workshops in industry such as aircraft, automobiles, refrigerators, washing machines, and other transportation and home appliances equipment shell production Enterprises.
