Lengéscsillapító puffervizsgáló gép
Main uses:Evaluation of shock absorption and cushioning performance: The shock absorption and cushio
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
Tartalom
Standard
- SATRA TM142: Measures energy absorption, rebound resilience, and indentation resistance of footwear midsoles, insoles, and packaging materials.
Product Advantages
1. Uncompromising Precision
- Hemispherical Impactor: 45mm diameter (37.5mm radius) ensures repeatable contact geometry.
- 8.5kg Calibrated Mass: ±0.01kg tolerance for ISO 179-1 equivalent energy calculations.
2. Versatile Testing
- Multi-Material Compatibility: Evaluates EVA foams, gels, composites, and corrugated packaging.
- Adjustable Drop Height: 10–1,000mm range for low-speed to high-energy impacts.
3. Advanced Sensing
- Dual-Channel Acquisition: Simultaneously captures acceleration (10,000 Hz) and displacement (0.01mm resolution).
- Auto-Calculated Metrics: Rebound energy, indentation depth, and damping ratio displayed in real-time.
4. User-Centric Design
- Quick-Release Mechanism: Tool-free height adjustment via magnetic safety interlocks.
- 7” Touchscreen HMI: Pre-loaded SATRA TM142 protocols with adjustable test parameters.
5. Data Integrity
- 21 CFR Part 11 Compliance: Audit-ready electronic records with e-signatures.
- Cloud Integration: Wireless sync to LIMS platforms for collaborative R&D.
Product Features
- Impact System:
- Servo-controlled release mechanism with 0.1mm positional accuracy.
- Hardened steel impactor with tungsten carbide coating for wear resistance.
- Sensing Suite:
- Piezoelectric accelerometer (±5,000g range).
- Laser displacement sensor (0.01mm resolution, 500mm range).
- Safety Systems:
- Acrylic enclosure with interlock sensors.
- Emergency stop with E-Stop loop monitoring.
- Software Bundle:
- ShockVision Pro™: Real-time force-time curves and energy loss calculations.
- MaterialDB: Store/compare test results across material batches.
- Data Management:
- USB 3.0 port for raw data export.
- API integration with MATLAB/Python for custom analysis.
Műszaki paraméterek
| Specifikáció | Részletek |
|---|
| Impact Mass | 8.5 kg ±0.01 kg (18.7 lbs) |
| Drop Height Range | 10–1,000 mm (0.4–39.4”) |
| Max. Impact Velocity | 4.43 m/s (1,000mm drop) |
| Accelerometer Range | ±5,000g (1g = 9.81 m/s²) |
| Displacement Resolution | 0.01 mm (0.0004”) |
| Data Rate | 10,000 Hz (acceleration) |
| Tápegység | 220V/50Hz (110V/60Hz available) |
| Dimensions (W×D×H) | 600mm × 500mm × 1,800mm |
| Súly | 150 kg (net) |
Accessories & Options
- Calibration Kit:
- NIST-traceable accelerometer and displacement sensor.
- Weight verification set for impactor mass.
- Software Add-Ons:
- Fatigue Predictor: AI-driven lifespan estimation via cumulative damage modeling.
- CloudLink: Remote monitoring for global teams.
- Safety Upgrades:
- Explosion-proof enclosure for solvent-resistant testing.
- HEPA filtration for particle-sensitive labs.
- Custom Fixtures:
- High-temperature clamps for thermoplastic testing.
- Cryogenic chamber adapter for low-temperature impact studies.
- Consumables:
- 20 × Disposable sample alignment targets.
- 1L Silicone lubricant for high-cycle testing.
