Környezeti feszültség-repedésvizsgáló gép

Standard

• ASTM D1693: Exclusively designed for bending beam and constant load tests on polyethylene and other thermoplastics.
• ISO 22088-3: Configurable for notched specimen testing in aggressive media.

Product Advantages

1. Unmatched Throughput

• 460-Sample Capacity: Test up to 460 specimens simultaneously (46 vessels × 10 samples/vessel).
• High-Efficiency Design: 40% faster batch testing than competitive models.

2. Precision Engineering

• Uniform Stress Application: Compliant with ASTM D1693’s 2.75mm bending beam specification.
• PID Temperature Control: ±0.2°C stability across -10°C to 100°C range.

3. User-Centric Workflow

• Smart Sample Prep: ASTM-compliant milling tools and prefabricated specimen jigs included.
• Intuitive Touchscreen: Pre-loaded ASTM protocols with adjustable hold times (1–1,000 hours).

4. Safety & Compliance

• Chemical-Resistant Construction: 316L stainless steel bath and PTFE-coated components.
• Audit-Ready Reporting: 21 CFR Part 11 compliant data logging with electronic signatures.

5. Adaptive Testing

• Solvent Versatility: Compatible with surfactants (soap), hydrocarbons (oils), and polar solvents (alcohols).

Product Features

• Modular Bath System:
  • 46-position carousel with quick-release glass vessels (250mL capacity).
  • Dual-circuit heating for rapid temperature equilibration.
• Stress Loading System:
  • Manual or motorized bending fixtures with 0–50N load range.
  • Laser-aligned specimen grips for consistent strain distribution.
• Chemical Management:
  • Integrated solvent level sensors with low-volume alerts.
  • Vented enclosure for fume extraction (compatible with external HVA systems).
• Data Integrity:
  • 100Hz sampling rate captures crack initiation events.
  • Wireless data export via Wi-Fi/Bluetooth to LIMS platforms.
• Safety Suite:
  • Leak-proof magnetic drive stirrers.
  • Emergency solvent dump system with CO₂ fire suppression.

Műszaki paraméterek

Accessories & Options

1. Sample Preparation Kit:
   • ASTM D1693-compliant milling cutters and polishing films.
   • Prefabricated specimen jigs for 2.75mm bending beams.
2. Solvent Management:
   • Explosion-proof storage cabinet for flammable liquids.
   • Recirculating chiller for sub-ambient testing (-10°C).
3. Advanced Analytics:
   • CrackVision™ Software: AI-assisted image analysis for crack length measurement.
   • LabCloud Pro: Remote monitoring for 100+ concurrent users.
4. Calibration Bundle:
   • NIST-traceable temperature/force calibration kit with certificate.
5. Extended Warranty:
   • 5-year comprehensive coverage for bath and controls.
