Curtain Combustion Tester

Alkalmazás

• Window coverings in commercial/residential buildings.
• Textile products used in public spaces (theaters, hotels).
• Construction fabrics and banners.

Szabványok

• NFPA 701 (2004 & 2009 Edition, Test Method 1): Standard for flame resistance of fabrics and films.

Product Advantages

1. Precision Testing: Vertical sample mounting with standardized 45-second ignition.
2. Automated Control: Touchscreen operation with automatic ignition/exhaust.
3. Isolated Environment: Sealed test chamber minimizes external interference.
4. Adjustable Flame: Meker burner with 100mm adjustable height for varied testing needs.
5. Data Accuracy: Measures combustion time (±0.1s) and weight loss post-test.

Product Features

• Vizsgálati elv: Samples are moistened, vertically clamped, and exposed to a Meker burner flame for 45 seconds. Flame spread and combustion duration are recorded.
• Key Components:
  • Test Chamber: Black interior with transparent observation window (675×500×700mm).
  • Sample Clamp: Parallel longitudinal mounting at 150mm×400mm, with adjustable nail positions (37mm, 66mm, 95mm, 124mm, 153mm).
  • Exhaust System: Automatic emission control for smoke/fumes.
• Ignition: Automatic flame application with 100mm height adjustment.

Műszaki paraméterek
