Tartalom
Alkalmazás
- Textile Industry: Assesses carpet pile integrity for residential, commercial, and automotive applications.
- Minőségi ellenőrzés: Validates compliance with international appearance change standards.
- Research & Development: Tests material resistance to abrasion, crushing, and pile distortion.
- Certification Labs: Provides data for SATRA, ISO, and BSEN certification.
Standard
- BSEN 1471:1997: Evaluation of Appearance Changes in Floor Coverings
- ISO 9405:2001: Floor Coverings – Determination of Appearance Change After Simulated Traffic
- ISO 10361:2000: Carpet Appearance Evaluation Using Tumbler Testers
- IWS/Wools of New Zealand Methods 247 & 251: Pile Fabric Abrasion Resistance
Product Advantages
- Realistic Wear Simulation: Reciprocating mechanism replicates foot traffic and pile compression.
- Rapid Testing: Completes substrate-based barrel tests within one working day.
- Adjustable Parameters: Preset rotations (0–999,999 cycles) via digital counter.
- Replaceable Components: Polyurethane hexapod feet (3.8 kg) last 2+ years and are easily replaceable.
- Safety Design: Hinged cover with sensors prevents accidental access during operation.
- Global Compliance: Meets BSEN, ISO, and IWS standards for carpet performance.
Product Features
- Hexapod Foot Design: Six polyurethane feet (3.8 kg total) mimic human walking pressure.
- Reciprocating Drum: Rotates at 35 ±2 RPM to simulate bidirectional traffic.
- Substrate Testing: Accommodates steel balls or textile samples in the 200 mm deep chamber.
- Digital Control: Touchscreen panel for cycle preset, speed adjustment, and real-time monitoring.
- Easy Maintenance: Quick-release hexapod feet and corrosion-resistant stainless steel drum.
- Wall Thickness: 8 mm drum construction ensures durability.
Műszaki paraméterek
| Paraméter | Specifikáció |
|---|
| Control Panel | Touchscreen Timing Module |
| Hexapod Foot Weight | 3.8 kg (Six Polyurethane Feet) |
| Power Consumption | 0.5 kW |
| Rotational Speed | 35 ±2 RPM |
| Drum Internal Depth | 200 ±1 mm |
| Cycle Counter Range | 0–999,999 (Presettable) |
| Wall Thickness | 8 mm (Stainless Steel) |
| Tápegység | AC 220V ±10%, 50Hz |
| Dimensions (L×W×H) | 900 mm × 500 mm × 570 mm |
| Net Weight | 75 kg |
| Safety Cover | Hinged with Sensor Interlock |
